Nano-N3281
Intel Core Ultra. Eight 2.5G ports. No fan.
Eight ports.
All of them 2.5G.
Built for firewall, VPN, router and network-server roles. Runs Windows 10/11, Linux, pfSense and iKuai.
Open it up.
Keep scrolling. The layers below come straight from the factory CAD.
Intel Core Ultra, 15 W.
Core Ultra 5 125U or Core Ultra 7 155U: 12 cores, 14 threads, plus the Intel AI Boost NPU.
Up to 64 GB DDR5. NVMe at PCIe 4.0.
Two DDR5-5600 SODIMM slots. One M.2 2280 NVMe (PCIe 4.0 ×4) plus a 2.5-inch HDD/SSD bay.
Wi-Fi, 4G/5G, three displays.
M.2 E-key for Wi-Fi, M.2 B-key for 4G/5G with external SIM slot. HDMI, DP and Type-C, up to 4096 × 2160 at 60 Hz.
Look through the shell.
The processor sits on top of the mainboard, directly under the aluminium lid.
Heat goes up, into the metal.
With no fan inside, the enclosure itself carries heat away from the 15 W processor.
The fins do the rest.
Heat spreads across the finned top and leaves by natural air flow. Rated −20 to 50 °C with an industrial SSD.
Made for the back-plate.
170 × 140 × 58 mm, 1.36 kg. Fit it with the optional side wall-mount kit (179 × 80 mm holes) or the included VESA 75/100 bracket.
Nano-N3281
Regional supply and technical support from IWILL MENA. Tell us the quantity and configuration and we reply with a quote.
| Processor | Intel Core Ultra 5 125U / Ultra 7 155U, 15 W, Intel AI Boost NPU |
|---|---|
| Memory | 2 × DDR5 5600 SODIMM, max. 64 GB |
| Storage | 1 × M.2 2280 M-key NVMe (PCIe 4.0 ×4), 1 × 2.5" HDD/SSD |
| Ethernet | 8 × 2.5G: 1 × Intel i226-LM (vPro, LAN1), 7 × Intel i226-V |
| Front I/O | 4 × USB 3.2, Type-C (DP/USB 3.2), HDMI, DP, RJ45 console, SIM slot |
| Wireless | M.2 2230 E-key (Wi-Fi), M.2 3052/2242 B-key (4G/5G) |
| Security | TPM 2.0, watchdog 0–255 levels |
| Power | DC 12 V |
| Environment | 0–40 °C (commercial HDD), −20–50 °C (industrial SSD), 5–95 % RH non-condensing |
| Size / weight | 170 × 140 × 58 mm, 1.36 kg |
| Certification | CE, CCC, FCC Class A, RoHS |
Specifications subject to change
