Nano-N3261 Firewall Appliance – front panel with four 2.5GbE LAN and two 10G SFP+ ports
Network Security

Nano-N3261 – Firewall Appliance (OPNsense/pfSense)

Key features

  • Intel Core i5-1235U / i7-1255U (10 cores, 12 threads)
  • 2x 10GbE SFP+ (Intel 82599)
  • 4x Intel i226 2.5GbE LAN
  • DDR5 4800MHz up to 64GB (2x SODIMM)
  • Fanless design
  • RJ45 console port

Request a Quote

Send your quantity, configuration and application requirements to discuss pricing and availability.

Send Enquiry

Nano-N3261 specifications

Technical specifications
ProcessorIntel Core i5-1235U / i7-1255U (10 cores, 12 threads, up to 4.7GHz)
Memory2x DDR5 4800MHz SODIMM, up to 64GB
Network4x Intel i226 2.5GbE + 2x 10GbE SFP+ (Intel 82599)
Display1x HDMI + 1x DisplayPort + 1x USB-C (video)
Storage1x M.2 2280 + 1x 2.5" HDD/SSD
I/O2x USB 2.0, 2x USB 3.2, 1x RJ45 Console
Dimensions170 × 140 × 58mm
FeaturesIntel vPro (LAN1), PXE, Wake-on-LAN, Watchdog
Operating environment
Operating Temperature-10°C to 60°C
Storage Temperature-20°C to 70°C
Humidity5% - 95% non-condensing

Supported OS

  • pfSense
  • OPNsense
  • Linux (Ubuntu/Debian)
  • Windows 10/11

Expansion & connectivity

  • 1x M.2 2280
  • 1x 2.5" HDD/SSD

Nano-N3261 is a fanless firewall appliance that pairs an Intel 12th-generation Core i5-1235U or i7-1255U with four Intel i226 2.5GbE ports and two 10GbE SFP+ ports (Intel 82599). With up to 64GB DDR5 and an RJ45 console port, it is built for enterprises, ISPs and data centres in the Gulf that are moving to 10G fibre uplinks and need firewall, SD-WAN or intrusion-detection workloads to keep up.

Typical applications in the Gulf and MENA

  • Enterprise perimeter firewalls with 10G fibre uplinks
  • SD-WAN hubs linking branches across GCC countries
  • ISP edge security and traffic shaping
  • IDS/IPS appliances in data centres

Operating environment

Nano-N3261 is rated for wide-temperature operation from -10°C to 60°C (storage -20°C to 70°C). That headroom matters in the Gulf, where equipment cabinets, kiosks and plant rooms run well above room temperature through the summer. The fanless design has no fan to clog with dust or sand, which cuts maintenance on remote and dusty sites.

Software and language support

Supported operating systems: pfSense, OPNsense, Linux (Ubuntu/Debian), Windows 10/11. We can pre-load pfSense or OPNsense before shipping, and our team supports configuration and handover in Arabic and English.

Availability and lead time

IWILL MENA quotes every configuration per project, from CPU, memory and storage to OS and I/O options. Units ship from stock in Hong Kong; availability and lead time to your site are confirmed on quotation. Send us the model, quantity and delivery country and we will come back with a formal quote.
